New Guest Cottages, Yosemite Lodge 1962 - Heating Water Distribution

New Guest Cottages, Yosemite Lodge 1962 - Heating Water Distribution

Architectural blueprints showing planned additions to Yosemite Lodge, including existing boiler room plan, manholes, conduits, heating water distribution, space heating, job no. 6209, sheet M1 of 21

Item Number YOSEMCA1125_M1, Scan Number: YOSE_MCA_-0078

Contact Yosemite National Park for more copyright information and use

Restrictions apply on use and/or reproduction


Yosemite National Park, Code: YOSE

Yosemite National Park, California
Yosemite National Park, California
Latitude: 37.8399200439453, Longitude: -119.540397644043

County of Mariposa Collection

1963/07/05

07/05/1963

Type: Blueprint, Dimensions: 40.5 x 28.5

Public Can View

Spencer and Lee

Person: Archivist
Organization: US National Park Service
Address: Yosemite National Park Archives, PO Box 700-W, El Portal, CA 95318
