HP and IP Piston valves - stems and liners, 1903 October

Multiple named vessels, including YOSEMITE (built 1906; steam schooner), NORWOOD (built 1904; steam schooner), and SAGINAW (built 1907; steam schooner).Plan is marked with the Fulton Iron Works number W3398 and the Main Street Iron Works number W-507.

U. S. National Park Service

Permission must be secured from the individual copyright owners to reproduce any copyrighted materials contained within this website. Digital assets without any copyright restrictions are public domain.

Restrictions apply on use and/or reproduction:This image is for research and study purposes only. This work may be protected by U.S. copyright law (Title 17, U.S. Code), which governs reproduction, distribution, public display, and other uses of protected works. Uses may be allowed with permission from the copyright holder, or if the copyright on the work has expired, or if the use is "fair use" or within another exemption. The user of this work is responsible for compliance with the law.


San Francisco Maritime National Historical Park, Code: SAFR

NPS Museum Number Catalog : SAFR 278
Local Park number : HDC0487, Series 1, File Unit 1, Item 253-103-168

Main Street Iron Works plans, 1901-1921
San Francisco Maritime Digital Museum Archival Collection

Title: Guide to the Main Street Iron Works plans, 1901-1921 located on the Online Archives of California website.
URL: http://www.oac.cdlib.org/findaid/ark:/13030/c8br8v9m/

08/19/2016

1 ink on linen.
